Premium Chimei POLYLAC® PA-707K ABS raw material with high flowability and surface gloss. Ideal for home appliances, electronics, and food-contact parts.
| Manufacturer | Chimei |
|---|---|
| MVR | 2.1 cm³/10 min |
| Density | 1.05 g/cm³ |
| Elongation at Break | 20 % |
| Flexural Modulus | 2600 MPa |
Note: See the product description for additional technical specifications
Chimei POLYLAC® PA-707K ABS is a high-performance acrylonitrile-butadiene-styrene (ABS) plastic resin manufactured by Chimei Corporation, a world-renowned polymer manufacturer. This grade is a general-purpose and engineering-grade modified ABS material, appearing as uniform natural-colored or translucent solid pellets.
As one of the representative grades in the Chimei POLYLAC® ABS lineup, PA-707K holds a prominent position in the plastics processing industry due to its high flowability, superior mechanical rigidity, and good processing stability. Specially optimized for complex structural parts and thin-wall injection molding, this material helps shorten cycle times while maintaining excellent surface finish and dimensional stability. PA-707K is widely used in home appliance housings, electrical and electronic components, office equipment, and specific food-contact applications, making it an ideal raw material choice for plastics processors and engineering specifiers worldwide.
| Physical Properties | Test Value | Unit | Test Standard |
| Melt Volume-Flow Rate (MVR) 200°C, 5 kg | 2.1 | cm³/10 min | ISO 1133 |
| Melt Volume-Flow Rate (MVR) 220°C, 10 kg | 23 | cm³/10 min | ISO 1133 |
| Rockwell Hardness R | 116 | — | ASTM D785 |
| Density 23°C | 1.05 | g/cm³ | ISO 1183 |
| Mechanical Properties | Test Value | Unit | Test Standard |
| Tensile Strength 50 mm/min | 48 | MPa | ISO 527 |
| Tensile Strain, Break 50 mm/min | 20 | % | ISO 527 |
| Flexural Strength 2 mm/min | 73 | MPa | ISO 178 |
| Flexural Modulus 2 mm/min | 2600 | MPa | ISO 178 |
| Izod Notched Impact Strength 4 mm, 23°C | 15 | kJ/m² | ISO 180 |
| Charpy Impact Strength 4 mm, 23°C | 16 | kJ/m² | ISO 179 |
| Thermal Properties | Test Value | Unit | Test Standard |
| Vicat Softening Temperature 50°C/h, 10 N | 104 | °C | ISO 306 |
| Heat Deflection Temperature 1.8 MPa | 98 | °C | ISO 75-2 |
| Heat Deflection Temperature, Unannealed 1.8 MPa | 83 | °C | ISO 75-2 |
| Flammability Rating 1.5 mm | HB | — | UL 94 |
Disclaimer: The technical data sheet (TDS) of POLYLAC® PA-707K ABS material from Chimei corporation, if there are differences, please refer to the official website of Chimei.
High Melt Flowability: Features a high melt volume-flow rate (23 cm³/10 min at 220°C/10 kg), providing a long flow path and low injection pressure, which significantly improves mold-filling efficiency for large complex parts and thin-walled components.
Balanced Mechanical Rigidity & Impact Resistance: Boasts a flexural modulus of up to 2600 MPa and a tensile strength of 48 MPa. While ensuring high structural rigidity, it maintains good Izod notched impact strength (15 kJ/m²).
Excellent Surface Finish & Processability: Delivers high surface gloss and stable shrinkage after injection molding, making it easy for post-processing such as painting, electroplating, ultrasonic welding, and machining.
Reliable Thermal Stability: Achieves a Vicat softening point of 104°C and a heat deflection temperature of 98°C, ensuring that parts remain structurally stable in ambient to moderate operating temperatures.
Environmental & Food-Contact Compliance: Complies with RoHS and REACH regulations. Specific batches meet food-contact compliance standards (FDA / EU) with low odor and low residual monomer content, making it suitable for applications with high hygiene requirements.
Owing to its high flowability, good mechanical rigidity, and excellent surface appearance, POLYLAC® PA-707K ABS is widely utilized across the following industry sectors:
Q1: What are the recommended drying conditions for POLYLAC® PA-707K ABS prior to injection molding?
A: ABS material is slightly hygroscopic; excessive moisture before processing can cause silver streaks, bubbles, or reduced mechanical strength on the product surface. Recommended drying parameters are as follows:
Drying Equipment: Hot air circulating oven or desiccant dryer.
Drying Temperature: 80°C – 85°C.
Drying Time: 2 – 4 hours (dry until moisture content is controlled below 0.1%).
Q2: What is the difference between POLYLAC® PA-707K and general-purpose standard ABS (e.g., PA-757)?
A: The main differences lie in flowability and rigidity emphasis:
PA-707K focuses on high flowability and high rigidity (higher melt index and superior flowability), making it more suitable for thin-wall molding, large complex injection molded parts, and shorter production cycles.
PA-757 is a high-impact general-purpose grade with slightly higher impact strength, but its melt flow rate is lower than that of PA-707K.
Q3: Does Chimei PA-707K ABS comply with international environmental and flame-retardant certifications (RoHS / UL)?
A: Yes. Chimei PA-707K complies with EU RoHS (2011/65/EU) directives and REACH (SVHC) regulations. Regarding flammability rating, this grade passes the UL 94 HB test at a thickness of 1.5 mm, categorizing it as a standard flammable engineering plastic. If your application requires a V-0 flame-retardant rating, it is recommended to select Chimei POLYLAC® flame-retardant series (such as PA-777D or PA-765).
