Dow AXELERON™ CS K-3364 NT CPD is a high-density polyethylene (HDPE) cable compound offering exceptional environmental stress cracking resistance, low-temperature toughness, and electrical stability for demanding power and communication cable jackets.
| Manufacturer | Dow |
|---|---|
| Density | 0.947 g/cm³ |
| MFR | 0.75 g/10min |
| Tensile Strength at Break | 500 MPa |
| Tensile Strength | 23.4 MPa |
Note: See the product description for additional technical specifications
CS K-3364 NT CPD HDPE is researched and manufactured by Dow, belonging to the AXELERON™ series, with the material classification of high-density polyethylene (HDPE). The physical appearance of the product is natural-colored pellets. This grade is a specialized HDPE material for cables, possessing a mature application foundation in the power and communication cable fields. The material features excellent environmental stress cracking resistance and electrical insulation properties, primarily adapted to extrusion molding processes, and is widely used in the manufacturing of cable insulation layers and jacket components.
| Property | Test Value | Test Unit | Test Standard |
| Density | 0.947 | g/cm³ | ASTM D792 |
| Melt Mass-Flow Rate (190°C, 2.16 kg) | 0.75 | g/10min | ASTM D1238 |
| Environmental Stress Crack Resistance (ESCR), 100% Surfactant (100°C) | >48.0 | hr | ASTM D1693 |
| Property | Test Value | Test Unit | Test Standard |
| Tensile Strength | 23.4 | MPa | ASTM D638 |
| Tensile Strain at Break | 500 | % | ASTM D638 |
| Tensile Strain Retention (100°C, 2 days) | 90 | % | ASTM D638 |
| Tensile Strength Retention – 2 Days (100°C) | 90 | % | ASTM D638 |
| Property | Test Value | Test Unit | Test Standard |
| Brittleness Temperature F00 | -76 | °C | ASTM D746 |
| Thermal Stress Crack Resistance F00 | >96 | hr | ASTM D2951 |
| Property | Test Value | Test Unit | Test Standard |
| Volume Resistivity (23°C) | >1.0E+15 | Ohms·cm | ASTM D257 |
| Dielectric Constant (1.0e+6 Hz) | 2.32 | — | ASTM D1531 |
| Dissipation Factor (After 14 days Water Immersion at 23°C, 1.0e+6 Hz) | 6.00E-05 | — | ASTM D1531 |
The technical data sheet (TDS) of Dow AXELERON™ CS K‑3364 NT CPD HDPE material from Dow corporation, if there are differences, please refer to the official website of Dow.
Outstanding environmental stress cracking resistance, reducing the risk of long-term cracking failure in cable service.
Excellent low-temperature toughness with a brittleness temperature down to -76.0°C, suitable for low-temperature laying conditions.
Stable electrical insulation properties with low dielectric loss, applicable to cable products requiring high insulation performance.
High retention rate of mechanical properties after thermal aging, maintaining mechanical integrity in high-temperature environments.
Good extrusion processing adaptability, with melt stability meeting the continuous production requirements of cable jackets and insulation layers.
Excellent water immersion resistance, maintaining a low dielectric loss level after immersion.
Communication Cable Field: Communication cable insulation layers and jacket materials, suitable for overhead and conduit-laid cables.
Power Cable Field: Medium and low-voltage cable jackets, and outer layer components requiring stress cracking resistance.
Underground Laid Cable Accessories: Direct-buried cable jackets and protective cable components subjected to soil stresses.
Electrical Extruded Products: Extruded electrical parts requiring high insulation, low-temperature resistance, and stress cracking resistance.
Q1: Does Dow AXELERON™ CS K‑3364 NT CPD HDPE require drying prior to processing?
A: HDPE has a very low moisture absorption rate and generally does not require pre-drying under normal storage conditions; when affected by moisture or condensation, it is recommended to dry at 60–70°C for 2–4 hours to remove surface moisture and prevent surface defects on products.
Q2: Does this grade come with RoHS compliance documentation?
A: This material can provide a RoHS conformity statement. During actual project reviews, compliance reports for the corresponding batch can be requested from the raw material supplier for verification.
Q3: What is the core difference between this grade and general-purpose cable HDPE?
A: This grade is specifically enhanced for environmental stress cracking resistance, thermal stress cracking resistance, and electrical stability after water immersion, making it suitable for severe long-term buried and alternating high-low temperature environments; general-purpose cable HDPE is relatively weaker in these long-term aging and crack-resistance metrics.
Q4: Can this material be blended with other polyolefins?
A: It is compatible with LLDPE and other HDPE types, and can be blend-modified to adjust processing fluidity or cost; however, stress cracking resistance and electrical properties will change after blending, so small-scale sample testing and verification must be completed before mass production.
