Get Covestro PC/ABS FR3010 at ZiJun Plastics. High-performance flame retardant (UL94 V-0) resin with MVR cm³/10min and superior toughness for electronics.
| Manufacturer | Covestro |
|---|---|
| Density | 1.18 g/cm³ |
| MVR | 15 cm³/10min |
| Tensile Modulus | 2700 MPa |
| Tensile Stress at Yield | 60.0 MPa |
| Tensile Streng at Break | 50.0 MPa |
Covestro PC/ABS FR3010 is a high-performance flame-retardant PC/ABS alloy material launched by Covestro, specifically designed for electrical, electronic, and high-safety requirement applications. This material combines the heat resistance of PC with the processing performance of ABS, while also featuring excellent flame-retardant properties.
Core Advantages:
Excellent Flame Retardancy: UL94 V-0 rating, suitable for products with high safety standards.
Good Mechanical Strength & Impact Resistance: Enhances product durability.
Outstanding Processing Flowability: Suitable for complex structures and thin-wall injection molding.
As a professional plastic raw material supplier, ZiJun Plastics provides stable supply, technical support, and global supply services to meet the engineering needs of various customers.
The following are the typical physical properties of Covestro PC/ABS FR3010 (reference values):
| Property | Value | Test Method | Test Condition |
| Density | 1.18 g/cm³ | ISO 1183 |
Standard Environment
|
| MVR | 15 cm³/10min | ISO 1133 | 240°C / 5kg |
| Tensile Modulus | 2700 MPa | ISO 527-2/1 | 23°C |
| Tensile Strength at Yield | 60.0 MPa | ISO 527-2/50 | 23°C |
| Tensile Strength at Break | 50.0 MPa | ISO 527-2/50 | 23°C |
Testing Notes:
MFR testing is determined according to the ISO 1133 standard under the condition of 260°C / 5kg.
Tensile and impact properties are tested in a standard laboratory environment (23°C).
The flame-retardant rating complies with UL certification standards and is suitable for the electrical and electronic industries.
Covestro PC/ABS FR3010 is widely used in the following industries:
Electronics:
Switch housings
Power adapter casings
Connector components
Advantage: Flame retardancy + Dimensional stability
Automotive:
Instrument panel components
Interior structural parts
Control module housings
Advantage: Impact resistance + Heat resistance
Consumer Electronics:
Laptop enclosures
Printer components
Smart device structural parts
Advantage: Appearance quality + Processing performance
PC/ABS vs ABS
| Comparison Item | PC/ABS FR3010 | General ABS |
| Flame Retardancy | V-0 (High) | Usually non-FR |
| Heat Resistance | High | Medium |
| Cost | Higher | Lower |
| Impact Strength | Higher | Average |
Conclusion: PC/ABS is more suitable for high-end electronics and applications with high safety requirements, while ABS is better suited for cost-sensitive products.
PC/ABS vs PC
| Comparison Item | PC/ABS | PC |
| Processing Performance | Better | More difficult |
| Cost | Lower | Higher |
| Toughness | High | Very high |
| Flame Retardancy | Customizable | Customizable |
Conclusion: PC/ABS achieves a better balance between performance and cost, making it a mainstream choice in industrial applications.
To achieve the best processing results, the following parameters are recommended:
Processing Parameters:
Drying Temperature: 80–100°C, 4–6 hours
Injection Temperature: 240–270°C
Mold Temperature: 60–90°C
Processing Advice:
It is recommended to use a dehumidifying dryer for pre-drying treatment.
Avoid material moisture, otherwise, it may lead to bubbles or silver streaks.
Control the injection speed to prevent material decomposition from affecting flame retardancy.
Proper processing conditions can significantly improve product appearance and performance stability.
Certifications & Compliance: Covestro PC/ABS FR3010 typically complies with the following international standards:
RoHS (Restriction of Hazardous Substances)
REACH (EU Chemical Regulation)
UL94 (Flame Retardant Certification)
(Specific certificates can be provided according to batches)
ZiJun Plastics Quality Assurance: As a professional plastics supplier, ZiJun Plastics provides:
Strict incoming material inspection processes
Batch stability control
Complete TDS / COA document support
Fast-response technical service
Ensuring every batch of material meets customer production and export requirements.
